PLAIN
Nordic design. Superior performance.
With a Nordic approach to design, balanced with functionality and aesthetics, the renowned Swedish lighting designer Kai Piippo created the Plain for Annell. Defined by its elegant straight lines, it adds a tasteful expression to your office. The suspended direct/indirect LED luminaire produces a medium beam downlight and a wide beam uplight, which adds perfect light and ambience to your office environment. Its lower UGR ensures excellent glare control.
Caractéristiques techniques
Profilé |
High-quality aluminium housing with structure lacquered matt black and white finish |
Dimensions des profilés |
1300, 1600 X 90mm |
Efficacité lumineuse | 130lm/W |
Puissance | 26 – 45W |
IRC | CRI > 80 / CRI > 90 / CRI > 95 (spectra) |
Cohérence des couleurs | MacAdam Step 3 |
Direct light output (lm) | 3250 - 10120lm |
température de couleur | 2700 / 3000 / 4000 / 5000K or TW 2700 - 5000K |
Gradation | Not dimmable / Switch DIM / Flicker-free dimming DALI / DALI 2-channels (direct/indirect) / Casambi / Pull switchDIM |
Optique | High-quality PMMA Diamond prism + Opal diffuser for direct light; High-quality PMMA Opal diffuser for indirect light |
Options |
Blanc dynamique |
Rated life | L90 B20 at 100.000 h, Ta=25 °C ambient temperature |
Configurateur
DOWNLOAD
DATASHEET
LDT
BROCHURE
MANUAL
DIMENSIONAL SKETCH
DOWNLOAD ALL
Options

Détection de présence et luminosité

Allumage intégré au luminaire
Commercial LED
Sunlike LED
Spectra technology
CRI 97
Perfect colour reproduction
