KYRA

Efficient lighting solution for classrooms and offices. UGR<16. 125lm/W.

The KYRA light fixture stands out with its sleek one-piece housing extending up to 3 meters, delivering superior quality illumination while maximizing efficiency. With various size options and available as a ceiling, pendant, or recessed luminaire, it is ideal for open-plan offices, classrooms, corridors, foyers, conference areas, and expansive environments.

Mounting type

Pendant

Ceiling

Recessed

T-bar

Uplight

Detail

Technical data

Housing	High-quality aluminium housing with powder coated finish in white RAL 9016, black RAL 9005 and grey RAL 9006 fine texture or special colour on request
Sizes	Standard sizes: Pendant/PDI: 706 / 776 / ...+/-70... 2806 mm Ceiling: 706 / 776 / ...+/-70... 2806 mm Recessed: 727 / 777 / ...+/-70... 2827 mm or continuous light-lines non-standard sizes are possible at +/-70mm *non-standard sizes are related to longer delivery times
Luminaire efficacy	125 lm/W
System power	16 – 59 W
Colour rendering	CRI > 80 / CRI > 90 / CRI > 95 (spectra)
Colour consistency	MacAdam Step 3
Light output (lm/m)	1900 - 6920lm/m
Colour temperature (K)	2700 / 3000 / 4000 / 5000K or TW 2700 - 5000 K
UGR	<16
Lighting control	NoDim / Pull-switch Dim / DALI-2 / 2CH DALI-2 / Casambi / 2CH Casambi
Optics	High-quality PMMA Diamond prism + Opal diffuser for direct light; High-quality PMMA Opal diffuser for indirect light
Options	EM 3h* Tunable white Stand-alone sensor Active+ Kyra Spectra (CRI97) KYRA C, KYRA P, KYRA R: available for dimensions longer than 1682mm KYRA PDI: available for dimensions longer than 1962mm
Rated life	L80 B20 at 100.000 h, Ta=25 °C ambient temperature
